8K HDMI 2x2 matrix

The Hangalaxy 8K HDMI 2x2 matrix switcher can switch either of the 2 HDMI input signals while assigning the 2 output HDMI signals to the display. Video bandwidth up to 40Gbps, video resolution up to 8K@60Hz 4:2:0. Supports intelligent EDID management and audio stripping (output via fiber and analog audio ports). At the same time, it has the function of splitter and switch, and can be widely used in demonstration scenes, video conferencing, multimedia teaching and other occasions requiring large-screen demonstration.
Enquiry

AdvantagePurposeProduct SpecificationScheme comparison

Functional characteristics

1. Complies with HDMI 2.1 and HDCP 2.3 specifications
2. Supports 40Gbps video bandwidth
3. Video resolution up to 8K@60Hz 4: 2:0 10bit, 8K@30Hz 4: 4:4 10bit, 4K@120Hz 4: 4:4 10bit
4. Supports VRR, FVA, ALLM
5. Supports HDR, HDR10, HDR10+, Dolby Vision, HLG transparent transmission
6. Supports HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
7. Built in equalizer, retiming, and driver program
8. Intelligent EDID management
9. Support audio stripping function (output through fiber optic and analog audio ports)
10. Support infrared remote control and front panel button switching.
11. Easy to install
